FC-3 series Flux Vector Control Inverter.

  • New generation of the modular category.
  • Flexible to satisfy diverse and specific customer requirements and industry demand.
  • Extension of design that meets general purpose of the customers, making it future ready for the inverters industry.
  • Provides equipment manufacturers with an all-in-one solution of high integration, while reducing system cost and improving system reliability thus delivering great value.
Technical Specifications at a Glance
  FC-3Series : General Magnetic Flux Vector Control Inverter
Input/Output-In-Terminal 5×DI (Bidirectional Input Non-high Speed),2×AI,1×DO,2×AO,1×Relay
Control Mode Open Loop Vector Control
V/F
Overload Capacity 130% rated current for 60 secs.
Communication Function Modbus (485 Communication Standard)
Customised Function
Customized functions Peripherals self-detection upon power-on It can conduct safety detections on the peripherals upon power-on, including earth and short circuit detections
Shared DC bus function It can realize the function that multiple inverters share the DC bus
JOG key Programmable key: Select the forward and reverse rotations / jog operation command
Traverse frequency control Multiple triangular-wave frequency control function
Timed control Timing control function: Setting time range from 0h to 65535h
Keypad extension line standardization Customers can use standard cable to extend the keypad

Modbus master slave: one drive can be configured as Master and can give speed and torque reference to slave drives.

Meets the requirements of all kinds of complicated high precision transmission with all functions of built-in universal extended interface, power speed control, torque control, practical process closed-loop control, simple PLC, flexible I/O terminal, pulse frequency given, frequency given channel and run command channel bundled, main auxiliary given control, swing frequency control, speed track, encoder break monitoring, internal break unit, 28 species fault monitoring, more than 16 MS speed control, parameters copies, etc.

FC-3 Series inverter is accordance with international standards, and some products have passed in CE standards

  • IEC/EN61800-5-1: Safety Regulation on Commissionable Electric Drive System
  • IEC/EN61800-3: Commissionable Electric Drive System
  • Third Part: Electromagnetic Compatibility Standard and Specific Testing Method for the Products
